• Centerfire Pistols: 7 yards with Rubber Impacts
• Light Carbines: 10 yards with Rubber Impacts
  • Ammo 3,000 FPS or less at the muzzle
• Centerfire Rifles (308/6.5CM): 20 yards with Rubber Impacts
  • Ammo 3,000 FPS or less at the muzzle
• Ammunition requirements:
  • NEVER use Armor Piercing or Penetrator Ammunition.
  • Ammunition OVER 3,000 FPS muzzle will result in more wear and tear on the system.
  • Hollow point/expanding ammunition IS acceptable, but WILL result in more rubber wear and tear.

Yes. This unit is FULLY serviceable. The entire upper assembly can be laid flat like a table while on the posts for a full teardown and servicing if need be.

No. Every exposed aspect of the upper assembly, including the handles and frame, are made from 3/8" AR550 steel. Every piece. Some competitors make the sides out of thin, lighter materials and that enables bullet passthroughs when shooting at angles. Not good.

That Depends entirely on the volume of your range. If you are using these traps with teams simply clearing rooms, these will last tens of thousands of rounds, for some folks the rubber will last for years. If you are doing higher volume competitive indoor shooting, the lifespan will be lesser. With that being said, this rubber is Vulcanized, 2" thick ballistic rubber. Not junk recycled, porous rubber. It's the best of the best and up to 25% more dense than most of our competitors rubber. We have customers who are replacing rubber at between 10-20K rounds for competitive uses. Replacement of rubber will depend on volume and style of ammunition used.

This answer is similar to above. Some customers use only pistols. These strike plates, especially 1/2" AR550, will last nearly indefinitely with pistol use and proper ammo. It is a wear item that depends on how many rounds your range shoots, the distance you shoot, and where the impacts are concentrated. Most customers will get years of use out of their strike plates.

We opted for adjustable lean for low or high angle engagements. For example, descending a flight of stairs. Bullets impacting at a 90 degree angle will do less rubber damage and the Mod 1 can be adjusted so bullet impacts are perpendicular to the strike plate. The same can be said for stadium engagements from elevated shooting positions. This is refinement that is much needed in bullet traps in general.

The short answer is daily. However we recognize that most will not clean the trap out daily. Cleaning daily reduces the chance of a clog inside the body of the trap. Shorter intervals of clean out are HIGHLY recommended. Users can also opt to leave the bucket below the system and leave the slide door removed. This can create more lead dust, so users must consider this during use.

Remove the lower six bolts for the front frame. Then you will have access to the funnel and can EASILY clean out the system without removing from the base or posts. Remember to wear proper PPE/respirator/gloves.

Yes! Some customers leave the funnel open and keep a bucket under the trap. This means lead will be constantly falling into the bucket. The downside of this is lead dust escaping the system. ONLY do this in proper indoor ranges with sufficient air filtration systems.

I mean...I guess you can. However proper ventilation is REQUIRED and you must adhere to local laws and regulations. Don't do something that is unsafe. Remember: Missed rounds need to be stopped. If you miss the trap, the bullet will hit something else. For that reason we really only recommend professional applications. That being said, we will sell to anyone who needs a high end bullet trap for their application.

Yes. This portable bullet trap ONLY ships via freight services. Note: We can fit up to five units PER skid. For this reason as you add multiples to your cart, you will see gradual increases in freight until you pass five units. For orders larger than five units or outside the US orders, contact us for estimates.

We produce our products in Lancaster County PA. We oversee every step of the process, QC, production, packaging, and shipping. From start to finish, TA Targets is manufacturing high quality systems for hard use. Our owners own the machinery, facility, equipment, etc. We have invested heavily in newer specialty equipment to further streamline our processes and increase quality even further.

No. The “armor” we use for the strike plates (actual target impact plates) is made from a proprietary material that is manufactured in Sweden. this is the best material we have found in the world. We were largely dissatisfied with the QC of American made strike plates and had too many issues with quality control. Eventually we hope a US manufacturer creates a material that is as available and as stringent as our Swedish plate. For now, this is the best material to service our customers. US Manufactured AR500 and AR550 is used in areas that are NOT main strike plates. Some examples of this are the Rifle Dueling Tree Shields, Plate Rack Shields, Arachnid front shield and hostage brackets.

Traditionally all other steel used in our systems is US origin.

Yes. The Rubber is produced in the US.

Maybe. Just in case, be sure not to eat the paint or lick the target before or after you’ve shot it. If you are just curious, led tastes horrible and will probably cause mental damage. If you have done it once you are likely to do it again. Handle at your own risk, if you choose, you may wear an industry grade hazmat suit and gas mask with a HEPA filter and good luck charm on your wrist. For more information visit https://oehha.ca.gov/proposition-65
